The HCAL 1104U is a precision generator of controlled Humidity and Temperature environment inside the chamber. It has huge volume of chamber size to perform a rapid and easy calibration of multiple portable instruments, sensors, transmitter, data logger of different manufacturers. The HCAL 1104U is to generate range from 5°C to 60°C / 3% RH to 95% RH and Psychometric Calculated Dew point indication range from -30°C to 45°C. It has an advantage of external Humidifier for easy maintenance and refilling of water, Semi portable and onsite transportable. The HCAL 1104U working in the principle of mixed flow method for generating the Humidity. A desiccant cell is used to De-Humidify the chamber for low Humidity and Humidifier generates high Humidity. A solid state Peltier element is used for heating and cooling the chamber. The HCAL 1104U improved version has metrology level performance in terms of Control stability and uniformity gradients.

7” True colour TFT Touch screen display

Wide range from 3% RH to 95% RH & 5°C to 60°C

Dew point temperature indication range -30°C to 45°C

Display Resolution 0.01%RH / 0.01°C

Improved design to provide metrology level performance in terms of chamber stability and uniformity gradient

Psychometric converted indication of Dew point, Wet bulb temperature etc.,.

Fast raising and Quick settling

Large chamber size

Replaceable front door to suitable for multi brand probe & portable indicator calibration

Semi portable and onsite transportable

Ideal for lab and field calibration

Solid state heating & cooling technology

ISO/IEC 17025 Accredited calibration certificate

Optional calibration software to record, Data analysis & generate calibration reports
